Approvals & Certifications
- ATEX (Ex II 1 GD, Exia IIC T Ga, Exia IIIC T120° C Da IP6X - 3000 Series), (Ex II GD, Exia II T G, Ex T IIIC T135° C Da IP6X - 3300/8300 Series)
- CUTR
- IEC (Ex II 1 GD, Exia IIC T Ga, Exia IIIC T120° C Da IP6X - 3000 Series), (Ex II GD, Exia II T G, Ex T IIIC T135° C Da IP6X - 3300/8300 Series)
- KOSHA
- NAMUR VDI/VDE 3845
- NEPSI
Bushing Material
- Aluminum Enclosure: Oil Impregnated Bronze
- Nylon
- Stainless Steel Enclosure: PTFE
Conduit Connection
- 1/2” NPT Conduit Entries
- 3/4” NPT Conduit Entries
- M20 Conduit Entries
- M25 Conduit Entries
Enclosure Finish
- Aluminum with Powder Coat Finish
Enclosure, Body Material
- Aluminum
- Engineered Resin
- Stainless Steel
- Stainless Steel with Electro-Polished Finish
Environmental Protection
- Intrinsically Safe
- IP66
- IP67
- IP68 - 3000/3300 Series
Materials of Construction
- 316 Stainless Steel - ASTM A351 CF8M, 1.4408
- Beacon Visual Indicator: Co-Polyester
- Hardware: Stainless Steel
Switch Type
- Magnum, SPDT (Hermetically Sealed Proximity Typical) Switches with Rhodium Contacts
- V3 Inductive NAMUR Proximity Sensors
- V3 SPDT Mechanical Switches, Gold-Plated Contacts
