Fluke 719Pro Electric Pressure Calibrator
Brand: Fluke CorporationThe 719Pro includes a full functioning loop calibrator that sources, simulates and measures mA signals and more making it the ideal test tool for calibrating high accuracy transmitters, pressure switches and pressure gauges.
Features- Unique integrated electric pump for one handed pressure calibration
- Test pressure switches easily with easy-to-use switch test function
- Precision pressure adjust vernier for easy and accurate pressure calibration
- Ideal accuracy and performance (0.025%) for reference class transmitter calibration
- 30 psi, 150 psi and 300 psi pressure ranges
- Programmable pressure calibrator pump limit:
- Eliminates over-pressurization
- Allows the user to program target pressures for pumping
- Extended pressure measurement range with any of 29 750P Pressure Modules
- Pump cleanout ports reduce pump failures from moisture and fluid damage
- Fluid trap included with the unit to mitigate chance of fluid damage in at-risk applications
- Precision temperature measurement with optional RTD probe
Specifications
Brand
Fluke-719Pro-30G
- Range: -12 to 30 psi / -0.8 to 2 bar
- Resolution: 0.001 psi / 0.0001 bar
Fluke-719Pro-150G
- Range: -12 to 150 psi / -0.8 to 10 bar
- Resolution: 0.01 psi / 0.001 bar
Fluke-719Pro-300G
- Range: -12 to 300 psi / -0.8 to 20 bar
- Resolution: 0.01 psi / 0.001 bar
Accuracy
- ± 0.025 % of Full Scale, 6 months
- ± 0.035 % of Full Scale, 1 year
Temperature Effect
- Add ± 0.002 % Full Scale/°C
Operating Temperature
- -10° C to +50° C
Connections
- Pressure: 1/8 inch Female NPT
- Electrical: Standard banana jacks
- RTD: 4 pin miniature circular
- External module: 6 pin miniature circular
